• Bright front bumper
• Front air dam
• Bright rear bumper
• Bright grille
• Body-color upper front fascia
• Black heated pwr exterior mirrors
• Tinted glass
• Variable speed intermittent windshield wipers
• Cargo lamp
• Trailer tow wiring-inc: 4-pin connector

• Cloth 40/20/40 split bench seat w/rear folding bench seat
• Front seat area floor carpeting
• Front floor mats
• Floor tunnel insulation
• 4-spoke steering wheel
• Tilt steering column
• Instrument cluster-inc: 120 MPH primary speedometer, tachometer
• Pwr windows w/driver one-touch down
• Pwr locks
• Remote keyless entry
• Speed control
• Air conditioning
• AM/FM stereo w/CD player-inc: CD changer control, (4) speakers
• Cigar lighter
• 12V pwr outlet
• Day/night rearview mirror
• Overhead console w/trip computer
• Passenger assist handle
• Passenger side visor vanity mirror
• Rear underseat compartment storage
• Glovebox lamp

• Driver/front passenger "Next Generation" airbags
• Pwr 4-wheel anti-lock disc brakes
• Front shoulder belt height adjusters
• Dual note horn

5.9L (360) HO I6 CUMMINS TURBO DIESEL ENGINE ($5,555)

• 750-amp battery
• electronically controlled throttle

• 3.73 Axle Ratio
• Anti-Spin Differential Rear Axle
• Cloth 40/20/40 Split Bench Seat
• Engine Block Heater
• Bodyside Molding
• AM/FM Compact Disc w/Changer Control
• Trailer Tow Group
• Sliding Rear Window
• Rear Folding Seat
• Air Close Out Front Panel
• Electronically Controlled Throttle
• Current Generation Engine Controller
• Class IV Receiver Hitch
• 7 Pin Wiring Harness
• 4 Speakers
• Speed-Sensitive Wipers
• Front beverage holders
• Variably intermittent wipers
• Tilt steering wheel
• Rear step bumper
• Power steering
• Passenger door bin
• Front anti-roll bar
• Dual front impact airbags
• Driver door bin
• Bumpers: chrome
• AM/FM radio
• ABS brakes
• Voltmeter
• Tachometer
• Front Center Armrest
• Air Conditioning
• 4-Wheel Disc Brakes

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 136
• Maximum Alternator Watts: 1904
• Cooling System
• Total Cooling System Capacity (qts): 32.7
• Total Cooling System Capacity (qts): 18.7
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 5200
• Gross Axle Wt Rating - Rear (lbs): 9350
• Curb Weight - Front (lbs): 3751
• Curb Weight - Rear (lbs): 3069
• Gross Vehicle Weight Rating Cap (lbs): 12200
• Gross Vehicle Weight Rating Cap (lbs): 11500
• Gross Combined Wt Rating (lbs): 23000
• Gross Combined Wt Rating (lbs): 17000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10050
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1005
• Suspension
• Suspension Type - Front: Coil
• Suspension Type - Rear: Leaf
• Axle Type - Front: Hypoid
• Axle Type - Rear: Full-floating
• Axle Capacity - Front (lbs): 5200
• Axle Capacity - Rear (lbs): 6500
• Axle Capacity - Rear (lbs): 6200
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.9 x 1.26
• Rear Brake Rotor Diam x Thickness (in): 13.9 x 1.18
• Tires
• Front Tire Size: LT235/80R17
• Rear Tire Size: LT235/80R17
• Spare Tire Size: LT235/80R17
• Front Tire Capacity (lbs): 2835
• Rear Tire Capacity (lbs): 2835
• Spare Tire Capacity (lbs): 2835
• Revolutions/Mile @ 45 mph - Front: 649
• Revolutions/Mile @ 45 mph - Rear: 649
• Revolutions/Mile @ 45 mph - Spare: 649
• Wheels
• Front Wheel Size (in): 17 x 6.0
• Rear Wheel Size (in): 17 x 6.0
• Spare Wheel Size (in): 17 x 6.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), On Center: 13.4
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 50.6
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 35
• Fuel Tank Location: Inboard Frame Rails
• Exterior Dimensions
• Wheelbase (in): 160.5
• Length, Overall w/o rear bumper (in): 249.7
• Width, Max w/o mirrors (in): 96.0
• Height, Overall (in): 79.1
• Overhang, Front (in): 39.4
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): 143.0
• Cab to Axle (in): 56.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 37.1
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 8.2
• Ground Clearance, Rear (in): 7.6
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.9
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 66.4
• Cargo Box Width @ Wheelhousings (in): 51.0
• Cargo Box (Area) Height (in): 20.2
• Tailgate Width (in): 60.6
• Cargo Volume (ft³): 74.9
• Ext'd Cab Cargo Volume (ft³): 41.0
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 40.9
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 67.0
• Front Hip Room (in): 65.1
• Second Head Room (in): 40.0
• Second Leg Room (in): 36.4
• Second Shoulder Room (in): 66.7
• Second Hip Room (in): 64.6
• Summary
• Vehicle Name: Dodge Ram 3500
• Body Style: Quad Cab 8' Box
• Body Code: 160.5" WB
